SKF YAR209-2F UC209

SKF Insert Bearing 45mm YAR 209-2F Description The SKF YAR 209-2F is a high-performance insert bearing, also known as a Y-bearing, designed for reliability and long service life. It features a 45 mm bore diameter and a spherical outer ring, allowing it to accommodate initial static misalignment when fitted in an appropriate housing. Locking is achieved via two grub screws in the inner ring, ensuring a secure fit on the shaft. This bearing is ideal for a wide range of industrial and agricultural applications. Specifications Manufacturer: SKF Bore Diameter: 45 mm Outside Diameter: 85 mm Width: 49.2 mm Locking Method: Grub Screws Sealing: Standard seal with flinger on both sides (-2F) Material: Bearing Steel Label Info Model: YAR 209-2F Alternative Designations: GYE 45 KRRB, UC209 EAN: 7316577032195 Application This insert bearing is commonly used in applications such as conveyor systems, agricultural machinery, food and beverage processing, and general industrial machinery where simple and effective bearing arrangements are required. Country of Origin Made in Italy. CO2 Impact Choosing this reused component prevents the emission of approximately 1.54 kg of CO2, which is equivalent to driving a car for over 7 kilometers. This reflects the savings from not manufacturing a new steel bearing. Availability This item is in stock and ready for immediate dispatch. Order now from profideals for expert support and fast delivery. FAQ What is the main advantage of the grub screw locking system on the YAR 209-2F?The grub screw locking system is simple, fast, and effective for applications where the direction of rotation is constant. It allows for easy installation and removal without damaging the shaft. What does the ‘-2F’ suffix in the model number signify?The ‘-2F’ suffix indicates a specific sealing arrangement. It means the bearing is equipped with a standard contact seal made from NBR rubber and an additional plain sheet steel flinger on both sides, providing excellent protection against contamination and moisture. Can this YAR 209-2F bearing be re-lubricated?Yes, SKF Y-bearings like the YAR 209-2F are typically supplied filled with grease and are designed to be re-lubricated. They have lubrication holes in the outer ring to facilitate this, extending their service life in demanding environments. Last Update: Friday, March 13, 2026 profideals is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners.
