SCHNEIDER ELECTRIC TSXTLYEX

Schneider Electric Modicon Bus X Terminator Set Description The TSXTLYEX is a set of two essential bus terminators designed by Schneider Electric for the Modicon series. These terminators are crucial for maintaining stable and error-free communication on Modbus Plus and Uni-Telway networks. By providing the correct termination impedance at both ends of the bus, they prevent signal reflections that can corrupt data and cause network failures. This set includes two terminators, A and B, to properly outfit a single network segment. Specifications Manufacturer: Schneider Electric Product Line: Modicon Model: TSXTLYEX Product Type: Bus Terminator Set Compatibility: Modbus Plus, Uni-Telway Connector: 9-pin SUB-D Quantity: Set of 2 Label Info Part Number: TSXTLYEX EAN: 3389110864243 Product Version (PV): 01 Application This terminator set is used in industrial automation environments with legacy Schneider Electric PLC systems. It is installed at the physical start and end of a Modbus Plus or Uni-Telway network cable to ensure reliable data transmission, particularly in long cable runs or high-speed applications. Country of Origin Made in China. CO2 Impact Opting for this pre-owned set of terminators instead of new production avoids the emission of approximately 2.0 kg of CO2, contributing to a more sustainable industrial operation. Availability This is an obsolete item, but it is available from our stock. Order now from profideals for expert support and fast delivery. FAQ What networks are these terminators for?These terminators are specifically designed for Schneider Electric’s legacy Modbus Plus and Uni-Telway networks. They are not suitable for other bus systems like Profibus or CANopen, which have different impedance requirements. Is this a complete set?Yes, the TSXTLYEX is sold as a complete set of two terminators, typically labeled A and B. Both must be used, one at each physical end of the network bus cable, for proper termination. What is the resistance value of these terminators?While not explicitly printed on the device, standard Modbus Plus terminators have a resistance of 120 ohms to match the characteristic impedance of the specified twisted-pair cabling and ensure signal integrity. profideals is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners. Last Update: Friday, March 13, 2026
