SEW EURODRIVE MDX61B0005-5A3-4-00 08277303

SEW Eurodrive MOVIDRIVE B 0.55kW Inverter Description The MDX61B0005-5A3-4-00 is a high-performance frequency inverter from SEW Eurodrive’s proven MOVIDRIVE B series. It is engineered for dynamic and precise control of asynchronous AC motors. This unit is an excellent choice for applications requiring reliable speed and torque control. As an obsolete part, it is a critical component for maintaining existing machinery without the need for extensive retrofitting. Order now from profideals for expert support and fast delivery. Specifications Power Rating: 0.55 kW / 0.75 HP Input Voltage: 3-phase 380 to 500V AC Input Frequency: 50 to 60 Hz Input Current: 1.80A AC Output Voltage: 3-phase 0V to U-input Output Current: 2.00A AC Output Frequency: 0 to 599 Hz Protection Class: IP20 Operating Temperature: 0 to +50 deg C Label Info Manufacturer: SEW Eurodrive Type: MDX61B0005-5A3-4-00 Part Number: 08277303 Serial Number: 01.7351059802.0001.16 Application Ideal for a variety of motion control applications including conveyor systems, pumps, fans, and general machine automation where precise motor speed control is essential. Country of Origin Made in Germany CO2 Impact By purchasing this reused component, you are helping to avoid the production of a new one, saving an estimated 100 kg of CO2. This is a sustainable choice for your business and the environment. Availability This item is a new old stock product in its original, opened box. Available for immediate dispatch. FAQ Can this MOVIDRIVE B MDX61B0005-5A3-4-00 be used as a direct drop-in replacement for an older unit?Yes, if the type number matches exactly, it is a direct physical and electrical replacement. However, always check and back up the parameters from the old unit before installation, as firmware versions can differ slightly. What communication options are available for this drive? Is it compatible with modern fieldbus systems?This base model comes with standard I/O and RS-485 with MOVILINK protocol. For fieldbus connectivity like PROFIBUS, DeviceNet, or EtherNet/IP, it requires an optional communication module which is not included with the standard unit. Since this model is obsolete, is programming software still available?Yes, the MOVITOOLS MotionStudio software used to program and commission the MOVIDRIVE B series is still available for download from the SEW Eurodrive website. It supports this model and allows for parameter setting, diagnostics, and scope functions. Last Update: Friday, March 13, 2026 profideals is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners.
