PEPPERL+FUCHS KFD2-EB2 189783

Pepperl+Fuchs KFD2-EB2 Power Feed Module Description The KFD2-EB2 from Pepperl+Fuchs is a high-reliability, 1-channel power feed module designed for intrinsically safe applications. It provides a 24 V DC supply to power 2-wire transmitters operating in hazardous areas, ensuring safe signal integrity. This module is part of the well-established K-System, known for its compact design and easy DIN rail mounting. Specifications Manufacturer: Pepperl+Fuchs Type: KFD2-EB2 Part Number: 189783 Supply Voltage: 24 V DC (20 to 30 V DC) Number of Channels: 1 Mounting: DIN Rail Application: Intrinsic Safety (IS) Barrier Label Info Manufacturer: PEPPERL+FUCHS Type: KFD2-EB2 Part No.: 189783 Ser. No.: 40000067721743 Application Ideal for use in process automation industries like oil & gas, chemical, and pharmaceutical, where sensors and transmitters are located in potentially explosive atmospheres. It isolates and protects control systems from field-side electrical faults. Country of Origin Made in Singapore. CO2 Impact By choosing this reused item, you are avoiding the emission of approximately 6.0 kg of CO2. This is equivalent to the CO2 absorption of a mature tree over a period of 3 months. Availability This item is in new condition, sealed in its original packaging. Order now from profideals for expert support and fast delivery. FAQ Question?What is the primary function of an intrinsic safety (IS) barrier like the KFD2-EB2? AnswerAn IS barrier is a safety device used in hazardous areas to limit the energy (voltage and current) supplied to field devices like sensors and transmitters. This prevents the electrical energy from becoming an ignition source for flammable gases or dust. Question?Can the KFD2-EB2 be used with any 2-wire transmitter? AnswerIt is designed for standard 2-wire transmitters that operate within its voltage and current specifications. However, it is crucial to perform an intrinsic safety loop calculation to ensure the combination of the barrier, cable, and field device complies with the safety standards for the specific hazardous area classification. Question?What does being part of the K-System signify? AnswerThe Pepperl+Fuchs K-System is a series of modular interface modules (IS barriers) that share a common housing and can be mounted on a standard DIN rail. Many K-System modules can also be mounted on a Power Rail, which simplifies wiring by providing power and a collective error message bus. profideals is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners. Last updated on: Friday, March 13, 2026
