LEUZE GS 06/66-2 50039567

Leuze GS 06/66-2 Forked Photoelectric Sensor Description The Leuze GS 06/66-2 is a robust forked photoelectric sensor engineered for high-precision detection tasks in industrial environments. With a 6mm fork width, it is ideally suited for applications like label detection on carrier materials, gear tooth sensing, and monitoring the presence of small components. This sensor operates on a versatile 10-30V DC supply and provides reliable performance. This unit is an obsolete but functional part, perfect for replacing existing sensors without system redesign. Specifications Manufacturer: Leuze Type: GS 06/66-2 Part Number: 50039567 Operating Voltage: 10 – 30V DC Fork Width: 6 mm Fork Depth: 42 mm Output Type: 2x Push-pull (PNP/NPN compatible) Light Source: Infrared LED Connection: Cable with rectangular connector Label Info Model: GS 06/66-2 Part No: 50039567 Serial No: 0707B480111 Input: 10-30V DC Application This sensor is commonly used in packaging machinery, printing presses, textile manufacturing, and automated assembly lines for precise object detection and positioning. Country of Origin Made in Germany. CO2 Impact Opting for this pre-owned sensor over a new one prevents the emission of approximately 6.0 kg of CO2, contributing to a more sustainable industrial operation. Availability This item is a used, tested product in excellent working condition. Order now from profideals for expert support and fast delivery. FAQ What is the switching principle of the GS 06/66-2?The datasheet for the GS 06 series indicates that these sensors are typically light-switching, meaning the output is active when the light beam is not interrupted. However, specific sub-models can vary, so it is always best to test its behavior in your specific application. Can this sensor be used to detect transparent labels?No, this model uses an infrared light source and is designed for detecting opaque objects. For transparent labels, a sensor with ultrasonic technology or specialized optics would be required. What is the pinout for the attached rectangular connector?The rectangular connector appears to be a non-standard addition. The sensor’s standard wire colors are indicated on the label (BN: +, BU: GND, WH/BK: Outputs). You would need to use a multimeter to trace these wires to the corresponding pins on the attached connector to determine its specific pinout. profideals is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners. Last Update: Friday, March 13, 2026
