SCHNEIDER ELECTRIC ATV71HC11N4

Schneider Electric Altivar 71 110kW Frequency Inverter ATV71HC11N4 Description The Schneider Electric Altivar 71 (ATV71) is a high-performance frequency inverter designed for constant torque applications with demanding performance requirements. This 110 kW model, ATV71HC11N4, is suitable for 3-phase synchronous and asynchronous motors. It offers a wide range of functions, including speed and torque control, making it ideal for complex industrial machinery. Although this series is now obsolete, it remains a sought-after spare part for maintaining existing installations. Specifications Manufacturer: Schneider Electric Series: Altivar 71 Model: ATV71HC11N4 Power Rating: 110 kW (150 HP) Input Voltage: 380-480 V AC, 3-Phase Input Frequency: 50/60 Hz Output Current: Dependent on motor and settings Control Type: Flux Vector Control Label Info Model: ATV71HC11N4 Product Line: Altivar 71 EAN: 3389119201049 Power: 110kW-150HP Voltage: 380/480 V 3-Phase Application This heavy-duty drive is typically used in applications such as material handling, cranes, process machinery, industrial elevators, and production lines where precise motor control and high torque are essential. Country of Origin Made in Austria. CO2 Impact Opting for a reconditioned part like this ATV71HC11N4 significantly reduces environmental impact. You help avoid the production of a new unit, saving an estimated 6200 kg of CO2, which is comparable to the emissions from driving a standard car for over 31,000 kilometers. Availability This item is a discontinued model but is available from our stock as a reliable spare part to ensure the longevity of your existing systems. Order now from profideals for expert support and fast delivery. FAQ Question?What communication protocols are supported by the ATV71HC11N4? The Altivar 71 series natively supports Modbus and CANopen protocols. Additional communication cards can be installed for other protocols like EtherNet/IP, Profibus DP, DeviceNet, and more. Question?Is a braking resistor included with this drive or does it need to be ordered separately? For a high-power drive like the 110 kW model, a braking resistor is not included and must be selected and ordered separately based on the specific application’s braking energy requirements. Question?Since the Altivar 71 is obsolete, what are the key considerations for migrating to its modern equivalent, the ATV900 series? When migrating, consider physical dimensions and mounting, wiring differences (especially for control terminals), and parameter conversion. The ATV900 series offers advanced features like built-in Ethernet and energy-saving functions, so programming will need to be adapted to leverage these benefits fully. Last Update: Friday, March 13, 2026 profideals is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
