HYDAC 4WE 10 HA S01-24DG/V 6071730

HYDAC 4WE 10 Solenoid Operated Directional Control Valve Description This HYDAC 4WE 10 HA S01-24DG/V is a high-performance, direct-operated directional spool valve designed for reliable switching in industrial hydraulic applications. It operates with a 24VDC solenoid and can handle pressures up to 350 bar. The valve features a standard NG10 (CETOP 5) mounting pattern for easy integration into manifold blocks. Its 4/3-way, closed-center design provides precise control for stopping and directing hydraulic flow. This unit is an excellent replacement or spare for demanding industrial machinery. Specifications Manufacturer: HYDAC Type: 4WE 10 HA S01-24DG/V Part Number: 6071730 Nominal Size: NG10 (CETOP 5) Max Operating Pressure: 350 bar Solenoid Voltage: 24VDC Spool Type: 4/3-Way, Closed-Center Seal Material: Viton (FKM) Label Info Made in Germany Nr./Baujahr: 08/17 Solenoid Coil P/N: 3135636 Application Suitable for a wide range of industrial hydraulic systems, including machine tools, presses, manufacturing lines, and mobile equipment requiring precise directional control of hydraulic actuators. Country of Origin Made in Germany. CO2 Impact By purchasing this reused HYDAC valve, you are preventing the emission of approximately 9.0 kg of CO2. This saving is equivalent to the CO2 produced by driving a car for 45 kilometers. Availability This item is in stock and ready for immediate dispatch. Order now from profideals for expert support and fast delivery. FAQ What is the mounting pattern for this valve? This valve uses a standard NG10 (Nominal Size 10) mounting interface, which corresponds to the CETOP 5 standard. This ensures interchangeability with other valves of the same size. What does the “/V” in the type number signify? The “/V” indicates that the valve is fitted with Viton (FKM) seals. These seals are suitable for a wider range of operating temperatures and offer enhanced resistance to mineral oils, synthetic fluids, and chemicals compared to standard NBR seals. Can the solenoid coil be replaced independently of the valve body? Yes, the solenoid coil (HYDAC P/N: 3135636) is a separate, replaceable component. It can be removed and replaced by unscrewing the retaining nut on the end of the solenoid tube, without needing to disturb the hydraulic connections. profideals is not an authorized distributor, reseller, or representative of the products featured on this website. All product names, trademarks, brands, and logos used on this site are the property of their respective owners. Last Update: Friday, March 13, 2026
