FAGET RM130-E10/2

FAGET RM130-E10/2 Current Transformer Description The FAGET RM130-E10/2 is a high-performance, window-type current transformer designed for mounting over busbars or primary conductors. It provides a scaled-down secondary current of 5A from a primary current of 2500A, suitable for measurement and protection devices in industrial electrical systems. Its robust construction ensures reliability and long service life in demanding environments. Specifications Manufacturer: FAGET Type: RM130-E10/2 Primary Current: 2500 A Secondary Current: 5 A Frequency: 50 to 60 Hz Max. System Voltage: 0.72 kV Burden / Accuracy Class: 10VA/Cl 0.5, 45-60VA/Cl 1, 75VA/Cl 3 Standard: IEC 60044-1 Label Info Ith: 60 In Fs: 15 Serial Code: 10/4M6611 Application Ideal for use in power distribution panels, switchgear, generator sets, and energy management systems for monitoring high current loads and for protective relaying. Country of Origin Manufactured in the Netherlands (NL). CO2 Impact Opting for this pre-owned component saves an estimated 80 kg of CO2 compared to a new purchase, supporting sustainable industrial practices. Availability This item is in stock and ready for immediate dispatch. Order now from profideals for expert support and fast delivery. FAQ What are the different accuracy classes (0.5-1-3) and VA ratings listed on this transformer for? This indicates the transformer has multiple performance levels. It achieves the highest accuracy, Class 0.5, at a lower burden of 10VA, suitable for precise metering. At higher burdens like 45-75VA, the accuracy decreases to Class 1 or 3, which is typically acceptable for protection relay applications. Is this transformer suitable for mounting on a DIN rail? No, this is a window-type or busbar-type current transformer. It is designed to be mounted directly over a large primary conductor or busbar. It does not have a DIN rail mounting clip. The standard listed is IEC 60044-1. Is this still a valid standard for new installations? IEC 60044-1 has been superseded by the IEC 61869 series of standards (specifically IEC 61869-2 for current transformers). While this transformer is fully functional and safe for replacement or existing systems, new installations may require components certified to the latest standard. Always check your local regulations and project requirements. Last Update: Friday, March 13, 2026 profideals is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners.
