Schneider Electric LC1D09 TeSys D Contactor with LAD4RCU Suppressor Description This is a Schneider Electric TeSys D series 3-pole contactor, model LC1D09. It is designed for high-reliability motor control applications. This unit comes pre-fitted with an LAD4RCU RC suppression module, making it suitable for circuits with a coil voltage of 110V to 250V AC. It offers a compact design, easy installation on a DIN rail, and a long mechanical and electrical life. Specifications Manufacturer: Schneider Electric Series: TeSys D Model: LC1D09 Attached Module: LAD4RCU (RC Suppressor) Poles: 3-Pole AC-3 Rating (at 400V): 9 A / 4 kW AC-1 Rating (Ith): 25 A Rated Insulation Voltage (Ui): 690V Rated Impulse Withstand Voltage (Uimp): 6kV Coil Voltage Compatibility (with module): 110-250V AC Built-in Auxiliary Contacts: 1 Normally Open (NO) + 1 Normally Closed (NC) Label Info Model Contactor: LC1D09 Model Module: LAD4RCU Part Number Module: 038545 EAN: 3389110385458 Application Ideal for controlling squirrel-cage motors in AC-3 applications and for resistive loads in AC-1 applications. Commonly used in HVAC, pumping, industrial machinery, and commercial building control panels. Country of Origin Made in France. CO2 Impact Choosing this reused component over a new one avoids approximately 14 kg of CO2 emissions, which is comparable to the emissions from a 70 km car journey. Availability This item is in stock and ready for immediate dispatch. Order now from profideals for expert support and fast delivery. FAQ What is the purpose of the included LAD4RCU module?The LAD4RCU is an RC (Resistor-Capacitor) suppression module. It is connected across the contactor’s coil (A1-A2 terminals) to dampen the high voltage spike that occurs when the coil is de-energized. This protects sensitive control electronics like PLC outputs from electrical noise and damage. Can I use this LC1D09 contactor without the LAD4RCU module?Yes, the contactor can function without the module. However, the coil’s electrical characteristics and the required control voltage will be different. You would need to verify the specific coil code (e.g., F7 for 110V AC, P7 for 230V AC) printed on the contactor’s body to ensure compatibility with your control circuit. The suppressor is highly recommended for PLC-controlled systems. What are the AC-1 and AC-3 ratings and when should I use them?The AC-3 rating (9A, 4kW at 400V for this model) is for inductive loads like squirrel-cage motors during starting. The AC-1 rating (Ith: 25A) is for non-inductive or slightly inductive loads, such as resistance heaters or lighting. Always use the AC-3 rating for motor applications, as it accounts for the high inrush current. Last Update: Friday, March 13, 2026 profideals is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners.
