SCHNEIDER ELECTRIC IMD-IM9 QZ13333

Schneider Electric Vigilohm IM9 Insulation Monitoring Relay Description The Schneider Electric IMD-IM9, part of the Vigilohm series, is an insulation monitoring device for IT (ungrounded) electrical systems. It provides continuous monitoring of the network’s insulation resistance to ground, triggering an alarm when the resistance drops below a user-defined threshold. This essential safety device helps prevent electric shock hazards and fire risks, ensuring operational continuity for critical power systems. Specifications Manufacturer: Schneider Electric Type: IMD-IM9 Reference Number: QZ13333 Product Range: Vigilohm Monitored Network Voltage [Un]: 0 to 480V AC (45-440 Hz), 0 to 480V DC Auxiliary Supply Voltage [Us]: 110 to 415V AC (45-440 Hz), 125 to 250V DC Alarm Resistance Range: 1 to 500 kOhm (adjustable) Time Delay: 1 to 10 seconds (adjustable) Output Relay: 1 C/O contact Mounting: DIN Rail Label Info Alarm Threshold: Adjustable via front dial Time Delay: Adjustable via front dial Operating Mode: Standard or Fail-safe, selectable Indicators: ON (green LED), Alarm (red LED) Application Ideal for use in industrial plants, hospitals (operating rooms), data centers, and marine applications where power continuity and electrical safety are paramount. It is specifically designed for AC and DC IT networks. Country of Origin Made in China. CO2 Impact Opting for a refurbished unit like this saves approximately 8.8 kg of CO2 emissions compared to purchasing a new one. This is equivalent to the CO2 absorbed by a mature tree in a year. Availability This item is in stock and ready for immediate dispatch. Order now from profideals for expert support and fast delivery. FAQ What type of electrical system is the IMD-IM9 designed for?The IMD-IM9 is specifically designed for ungrounded IT (Isulated Terra) electrical systems, both AC and DC, where the neutral is not connected to earth. Can the fail-safe mode be configured?Yes, the device has a switch on the front panel that allows you to select between ‘Std’ (Standard) and ‘Fail safe’ operating modes for the output relay. What is the purpose of the adjustable time delay?The adjustable time delay (T(s)) prevents nuisance alarms or tripping caused by brief, transient drops in insulation resistance, ensuring the alarm only triggers for sustained faults. profideals is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners. Last Update: Friday, March 13, 2026
