BALLUFF BTL5-S113-M0650-K-K05

Balluff Micropulse Linear Position Sensor with 560mm Stroke Description The Balluff BTL5-D512-M0560-A-N05 is a high-performance magnetostrictive linear position sensor from the renowned Micropulse series. It is engineered for non-contact and wear-free operation, delivering precise and absolute position measurement in challenging industrial environments. Its rod-style design is ideal for integration into hydraulic cylinders and other machinery requiring accurate feedback. This sensor ensures high reliability and a long service life. Specifications Manufacturer: Balluff Model: BTL5-D512-M0560-A-N05 Product Series: Micropulse BTL5 Measurement Principle: Magnetostrictive Stroke Length: 560 mm Output Signal: Digital Start/Stop Resolution: 10 micrometers Supply Voltage: 20-28V DC Housing Material: Stainless Steel Connection: 5 meter cable, flying leads Label Info Brand: Micropulse (by Balluff) Type: BTL5-D512-M0560-A-N05 Spec: 10 um / 24 V Application This sensor is commonly used in applications such as plastics processing machinery, metal forming, machine tools, hydraulic presses, and automated assembly lines where precise linear position control is critical. Country of Origin This product is typically manufactured in Germany. CO2 Impact Opting for a reconditioned sensor like this one prevents the emission of approximately 60 kg of CO2 compared to manufacturing a new one. This saving is equivalent to driving 300 km in a typical car. Availability This item is in stock and ready for immediate dispatch. Order now from profideals for expert support and fast delivery. FAQ Question?How do I mount the magnet for this BTL5 rod-style transducer?AnswerFor a rod-style sensor, a position magnet is required. This magnet is typically mounted to the moving part of the machine (e.g., the piston head inside a cylinder) and travels along the sensor rod without direct contact. Balluff offers various ring and U-magnets designed for different applications. Question?What is the output signal type for the ‘D’ interface in the model number?AnswerThe ‘D’ in the model number designates a digital Start/Stop interface. This is a time-based output protocol where the sensor sends out start and stop pulses, and the time difference between them is proportional to the magnet’s position. This requires a controller with a compatible interface card to interpret the signal. Question?Can the 5-meter cable on this sensor be shortened or extended?AnswerWhile it is technically possible to shorten the cable, it is not recommended to extend it. Extending the cable can introduce signal noise and timing issues, potentially affecting the accuracy of the measurement. If a longer cable is needed, it is best to order a sensor with the required length from the manufacturer. profideals is not an authorized distributor, reseller, or representative of the products featured on this website. All product names, trademarks, brands, and logos used on this site are the property of their respective owners. Laatst bijgewerkt: Friday, March 13, 2026
