BALLUFF BES0112 BES 516-377-G-E4-C-S49-00,3

Balluff Inductive Sensor M5 2mm BES0112 Description The Balluff BES0112 is a compact and reliable inductive sensor designed for precise detection of metal objects in automated systems. Featuring a rugged M5 stainless steel housing, it is built to withstand demanding industrial environments. This sensor is ideal for applications requiring accurate positioning, counting, or presence detection where space is a critical factor. Specifications Model: BES0112 Full Part Number: BES 516-377-G-E4-C-S49-00,3 Sensing Principle: Inductive Sensing Range (Sn): 2 mm Housing Size: M5 x 0.5 Operating Voltage: 10 to 30 V DC Output Type: PNP Switching Function: Normally Closed (NC) Connection: M8x1-Male connector, 3-pin Housing Material: Stainless Steel Label Info Rated operational current: < 200 mA Certifications: CE, EAC, cULus Listed Application This sensor is commonly used in factory automation, packaging machinery, assembly lines, and robotics for tasks such as part detection, end-of-travel sensing, and speed monitoring on metallic gears. Country of Origin Made in China. CO2 Impact By purchasing this reused item, you contribute to a circular economy and help avoid 1.0 kg of CO2 emissions associated with the production of a new unit. Availability This item is in stock and ready for immediate dispatch. Order now from profideals for expert support and fast delivery. FAQ What is the housing material of the BES0112 and is it suitable for harsh environments?The housing is made of high-grade stainless steel, making it robust and resistant to corrosion. It is well-suited for typical industrial environments, but for applications with aggressive chemicals or high-pressure washdowns, you should verify its IP rating and chemical compatibility. The part number mentions S49. What does this connector code mean?The S49 code in Balluff's nomenclature specifies a 3-pin M8x1 male connector. This is a common standard for compact sensors, ensuring broad compatibility with standard industrial cables. This is a PNP sensor. Can I use it with an NPN input on my PLC?This sensor has a PNP (sourcing) output. To connect it to an NPN (sinking) PLC input, you would typically need to use a pull-down resistor between the signal line and ground (0V). However, it is always recommended to use a sensor with an output type that matches your PLC's input type for the most reliable operation. Last Update: Friday, March 13, 2026 profideals is not an authorized distributor, reseller, or representative of the products featured on this website. All product names, trademarks, brands, and logos used on this site are the property of their respective owners.
