SKF 23038 CC/W33

SKF 23038 CC/W33 Spherical Roller Bearing Description The SKF 23038 CC/W33 is a high-capacity spherical roller bearing designed to withstand demanding operating conditions. Its robust construction allows it to accommodate misalignment and heavy loads, making it ideal for a wide range of industrial applications. The CC design ensures low friction and high operational reliability, while the W33 feature facilitates effective lubrication. Specifications Bore Diameter (d): 190 mm Outside Diameter (D): 290 mm Width (B): 75 mm Basic Dynamic Load Rating: 1160 kN Basic Static Load Rating: 1700 kN Limiting Speed: 2200 r/min Cage: CC design, two window-type steel cages Lubrication: W33 – Annular groove and three lubrication holes in the outer ring Label Info Manufacturer: SKF Part Number: 23038 CC/W33 EAN: 7316576601675 Application This bearing is commonly used in heavy machinery such as gearboxes, wind turbines, continuous casting machines, pumps, fans, and equipment in the mining and construction industries. Country of Origin Made in Sweden. CO2 Impact By purchasing this pre-owned bearing, you are contributing to a circular economy and have helped avoid approximately 36.4 kg of CO2 emissions. This is comparable to the emissions from driving a car for 182 kilometers. Availability This item is in stock and ready for immediate dispatch. Order now from profideals for expert support and fast delivery. FAQ What does the ‘CC/W33’ designation mean? The ‘CC’ refers to the internal design, which features two stamped window-type steel cages, a flangeless inner ring, and a guide ring centered on the inner ring. The ‘W33’ indicates that the bearing has an annular groove and three lubrication holes in the outer ring to facilitate efficient lubrication. Is this bearing suitable for high axial loads? Yes, spherical roller bearings like the 23038 CC/W33 are designed to accommodate not only heavy radial loads but also significant axial loads in both directions, making them very versatile for tough applications. What is the recommended clearance for this bearing? This bearing has a ‘Normal’ radial internal clearance as standard. For specific applications requiring a different clearance (e.g., C3 for higher temperatures/speeds), please consult the SKF technical documentation or our support team. Friday, March 13, 2026 profideals is not an authorized distributor, reseller, or representative of the products featured on this website. All product names, trademarks, brands, and logos used on this site are the property of their respective owners.
