SCHNEIDER ELECTRIC LRD32 034685

Schneider Electric TeSys LRD Thermal Overload Relay 23-32A Description The Schneider Electric LRD32 is a high-performance thermal overload relay from the TeSys LRD series, providing essential protection for motors against overcurrents. It offers a thermal setting range of 23-32A and is classified as Trip Class 10A, suitable for a wide range of standard motor protection applications. This relay is designed for direct mounting on TeSys D contactors (LC1D25, LC1D32, LC1D38) to create a compact and efficient motor starter. Features include a manual/automatic reset, a test/trip button, and high-quality construction for long-term reliability. Order now from profideals for expert support and fast delivery. Specifications Manufacturer: Schneider Electric Type: LRD32 Commercial Reference: 034685 Product Range: TeSys LRD Setting Range: 23-32 A Trip Class: Class 10A conforming to IEC 60947-4-1 Rated Insulation Voltage [Ui]: 690 V Network Frequency: 0…400 Hz Mounting Support: Direct on contactor or on rail with separate terminal block Auxiliary Contacts: 1 NO + 1 NC Label Info Model: LRD32 Part Number: 034685 EAN: 3389110346855 Serial: ENE0847E03BX Application This thermal overload relay is primarily used in industrial automation and control systems for motor protection in applications such as pumps, fans, conveyors, and machine tools. It prevents motor damage from overloads, phase failure, and prolonged starting times. Country of Origin Made in France. CO2 Impact Choosing this reused component saves an estimated 6.0 kg of CO2, which is comparable to the emissions from driving a standard car for 30 kilometers. Availability In stock. This unit is a new surplus item in its original box. FAQ What is the difference between Trip Class 10A and Trip Class 20?Trip Class 10A, like on this LRD32 relay, means the device will trip within 10 seconds at 7.2 times the set current. This is suitable for standard motor start-ups. Class 20 allows for a longer starting time (up to 20 seconds) and is used for heavy-duty applications with high-inertia loads. Can this LRD32 relay be mounted independently, or does it require a contactor?The LRD32 is designed for direct mounting onto Schneider Electric TeSys D contactors (models LC1D25, LC1D32, and LC1D38). For independent mounting, a separate terminal block, such as the LAD7B106, is required. How does the ambient temperature affect the performance of the LRD32?This is a bimetallic thermal overload relay, and its tripping characteristics are affected by ambient temperature. The LRD32 is temperature-compensated for operation between -20 deg C and +60 deg C. For temperatures outside this range, derating factors provided by Schneider Electric should be applied for accurate protection. Last Update: Friday, March 13, 2026 profideals is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners.
