SWARCO IG315/2STB AN047D 10

<h2>SWARCO IG 315/2 STB Induction Loop Detector</h2> <h3>Description</h3> <p>The SWARCO IG 315/2 STB is a robust two-channel induction loop detector designed for demanding applications in both traffic management and industrial automation. This specific unit features BEUMER branding, indicating its use within their sophisticated logistics systems. It operates on a versatile 24V AC/DC power supply and provides reliable detection of metallic objects passing over a connected induction loop. Configuration is made simple through accessible DIP switches for frequency and sensitivity adjustments.</p> <h3>Specifications</h3> <ul> <li>Manufacturer: SWARCO TRAFFIC SYSTEMS</li> <li>Model: IG 315/2 STB</li> <li>Part Number: AN047D 10</li> <li>Power Supply: 24V AC/DC</li> <li>Power Consumption: 3 VA</li> <li>Output: 2x Relay Contacts (Umax: 250V, Imax: 2A, Pmax: 60W)</li> <li>Inductance Range: 15 microH to 2000 microH</li> <li>Mounting: DIN Rail</li> <li>Protection Rating: IP30</li> </ul> <h3>Label Info</h3> <ul> <li>Serial Number: 491998 070260</li> <li>Year of Manufacture: 2012</li> </ul> <h3>Application</h3> <p>Ideal for vehicle detection at barriers, gates, traffic lights, and for object detection on industrial conveyor or sorting systems.</p> <h3>Country of Origin</h3> <p>Made in Germany.</p> <h3>CO2 Impact</h3> <p>Opting for this pre-owned component avoids approximately 8.0 kg of CO2 emissions compared to a new purchase, supporting sustainable industrial practices.</p> <h3>Availability</h3> <p>This item is in stock and ready for immediate dispatch. Order now from profideals for expert support and fast delivery.</p> <h3>FAQ</h3> <p><strong>What is the primary application for the IG 315/2 STB?</strong><br><p>Its primary application is the detection of vehicles or metallic objects via induction loops. It is commonly used in traffic systems, parking management, and industrial automation environments like conveyor sorting lines.</p> <strong>How do I set the sensitivity and operating frequency?</strong><br><p>Sensitivity and frequency are configured using the DIP switches on the front and side of the unit. The side label provides a basic guide for the switch settings. For precise calibration, consulting the official manufacturer’s documentation is recommended.</p> <strong>Can this detector differentiate between different types of vehicles?</strong><br><p>No, the IG 315/2 STB is a presence detector. It signals the presence or passage of a metallic mass over the loop but does not provide classification details such as vehicle type or size.</p></p> <p><em>profideals is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners.</em></p> <p>Laatst bijgewerkt: Friday, March 13, 2026</p>
