SCHNEIDER ELECTRIC iCT A9C20712

Schneider Electric Acti9 iCT Modular Contactor Description The A9C20712 from Schneider Electric is a high-quality modular contactor belonging to the trusted Acti9 range. It is designed for DIN rail mounting and is primarily used for controlling lighting circuits, heating systems, and other slightly inductive loads in residential, commercial, and industrial applications. This contactor ensures safe and reliable switching operations. Specifications Manufacturer: Schneider Electric Part Number: A9C20712 Product Range: Acti9 iCT Number of Poles: 2 Pole Contact Composition: 2 Normally Open (2NO) Rated Current: 16 A (AC-7a), 6 A (AC-7b) Control Circuit Voltage: 230…240 V AC 50 Hz Network Voltage: 250 V AC 50 Hz Mounting: DIN Rail Label Info EAN: 3606480097058 Model: iCT Standards: IEC/EN 61095 Application Ideal for load management applications such as public lighting, heating regulation, hot water systems, and ventilation. Its silent operation makes it suitable for installation in areas sensitive to noise. Country of Origin Made in France. CO2 Impact Opting for this reused component avoids the emission of approximately 4.4 kg of CO2, which is associated with the production of a new unit. This choice supports sustainable industrial practices by extending the product’s lifecycle. Availability This item is a tested, pre-owned product in excellent working condition. Available for immediate dispatch. Order now from profideals for expert support and fast delivery. FAQ Question?What is the difference between AC-7a and AC-7b utilization categories for this A9C20712 contactor?AnswerAC-7a is for slightly inductive loads in household appliances, like resistive heaters or lighting, allowing the full 16A rating. AC-7b is for motor-loads in household appliances, like fans or pumps, which has a lower rating of 6A due to the inductive inrush current. Question?Can I add an auxiliary contact block to this iCT contactor?AnswerYes, the Acti9 iCT series is designed to be modular. You can clip on an auxiliary contact block, such as the A9A26924 (1NO + 1NC), to provide additional signaling or interlocking functions. Question?What is the required wire size and tightening torque for the terminals?AnswerFor the A9C20712, the screw clamp terminals accept 1 to 4 sq mm solid or stranded cables. The recommended tightening torque is 0.8 Nm to ensure a secure and reliable connection. profideals is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners. Last Update: Friday, March 13, 2026
