SECO CTGPL2525-16 (75005988)

GDG code; B40 – TURNING, Item number; 75005988, Name Description; Value, B shank width; 25.0 mm, Barcode; Product barcode; 05988750000103, CSP; coolant supply property; 0, CTMS; connection text machine side; 2525, CTWS; connection text workpiece side; TP..1603../TP..32., DCINN; cutting diameter internal minimum; 25.00 mm, GAMO;; rake angle orthogonal; 5.0 deg, H; Height of tool holder shank; 25.0 mm, HAND; Direction of cutting; Left, ICS; Insert clamping system; C, ItemNumber; Item Number; 75005988, KAPR; tool cutting edge angle; 91.0 deg, KAPRC; Tool Cutting Edge Angle; Code G, LAMS; inclination angle 1.0 deg, LF; functional length; 150.00 mm, SC; Insert shape code; T, Shanktype; Shanktype; Square shank, Weight ;Net weight; 0.710 kg, VER; Version (Internal/External/Both) External, WF; functional width 32.2 mm.
