SCHNEIDER ELECTRIC ABL8WPS24400 ABL8WPS24400-01

Schneider Electric Phaseo Universal Power Supply Description The Schneider Electric ABL8WPS24400 is a high-performance, three-phase switched-mode power supply designed for demanding industrial automation applications. Part of the reliable Phaseo series, this unit converts a wide range of AC input voltages (380-500V) into a stable and adjustable 24 VDC output. With a powerful 960W capacity and 40A output current, it is perfectly suited for powering multiple components such as PLCs, motors, and sensors, ensuring consistent and clean power for your critical operations. Its robust metal housing and efficient cooling design guarantee longevity even in harsh environments. Specifications Manufacturer: Schneider Electric Series: Phaseo Type: ABL8WPS24400 Input Voltage: 3 x 380-500 V AC Frequency: 50/60 Hz Output Voltage: 24 V DC (adjustable from 24 to 28.8 V) Output Current: 40 A Power Rating: 960 W Protection: Overload, short-circuit, overvoltage, thermal Label Info Model: Phaseo ABL8 WPS24400 Input: 3x 380-500 VAC, 3x 2.4A, 50/60Hz Output: 24-28.8VDC, 40-33.33A, 960W MAX S/N: 0011385 Application This power supply is ideal for use in industrial control panels, manufacturing machinery, process automation, and any system requiring a high-current, stable 24 VDC source from a three-phase line. Country of Origin Made in China. CO2 Impact Opting for this pre-owned unit over a new one prevents the emission of approximately 100 kg of CO2, a significant saving that supports sustainable industrial practices. Availability This is an obsolete item, no longer in production by the manufacturer. Availability is limited to existing stock. Order now from profideals for expert support and fast delivery. FAQ Can this ABL8WPS24400 power supply be operated on a single-phase input?No, this model is specifically designed for a three-phase input voltage of 380 to 500 VAC. Operating it on a single-phase supply is not supported and may damage the unit. What is the purpose of the adjustment potentiometer on the front panel?The potentiometer allows for fine-tuning the output voltage within the specified range of 24 to 28.8 VDC. This is useful for compensating for voltage drops in long cable runs or for specific application requirements. Is this power supply suitable for parallel operation to increase output current?Yes, the Phaseo ABL8 series is designed to be connected in parallel to increase power or for redundancy. Refer to the official Schneider Electric documentation for correct wiring and configuration procedures to ensure proper load sharing. profideals is not an authorized distributor, reseller, or representative of the products featured on this website. All product names, trademarks, brands, and logos used on this site are the property of their respective owners. Last Update: Friday, March 13, 2026
