SCHNEIDER ELECTRIC ABE7-H16R21

Schneider Electric ABE7-H16R21 Modicon Telefast 2 Sub-Base Description The ABE7-H16R21 is a 16-channel relay output sub-base from the Schneider Electric Modicon ABE7 Telefast 2 family. It is engineered to provide a simple and reliable interface between your Modicon PLC (such as M340, Premium, or Quantum) and field devices. This module facilitates rapid connection via a 20-way HE10 connector and clearly labelled screw terminals, minimizing wiring effort and commissioning time. Specifications Manufacturer: Schneider Electric Product Range: Modicon ABE7 Model: ABE7-H16R21 Product Type: Plug-in sub-base for relay outputs Number of Channels: 16 Control Circuit Voltage: 24V DC Output Voltage Limits: 19 to 30V DC Connection Type: Screw-type terminals, HE10 connector Protection: 1.6A fast blow fuse per channel Label Info Brand: Schneider Electric Model: Modicon ABE7-H16R21 Input Ratings: 30Vdc max, 0.1A max/chan, 1.6A max/com Date Code: 3N-2013-W21 Application This sub-base is ideal for industrial automation applications requiring the switching of multiple DC loads. It is commonly used in manufacturing, process control, and building automation systems to connect PLC digital outputs to actuators, solenoids, contactors, and indicator lamps. Country of Origin Made in France. CO2 Impact Opting for this pre-owned ABE7-H16R21 module over a new one prevents the emission of approximately 12 kg of CO2. This saving is comparable to the carbon footprint of driving a car for 60 kilometers. Availability This item is in stock and ready for immediate dispatch. Order now from profideals for expert support and fast delivery. FAQ What type of PLC connector is used with the ABE7-H16R21? The ABE7-H16R21 uses a 20-way HE10 connector. It is designed for use with pre-formed Telefast cables (like ABE7CPAxx) to connect to Modicon M340, Premium, or Quantum PLC I/O cards. Are the output relays on this module replaceable? No, the relays on the ABE7-H16R21 sub-base are soldered to the PCB and are not designed to be user-replaceable. If a relay fails, the entire module typically needs to be replaced. What is the purpose of the fuse on this sub-base? The ABE7-H16R21 is equipped with a 1.6A fast-blow fuse for each channel. This provides overcurrent protection for the individual output circuits, protecting both the field device and the module itself from short circuits or overload conditions. profideals is not an authorized distributor, reseller, or representative of the products featured on this website. All product names, trademarks, brands, and logos used on this site are the property of their respective owners. Laatst bijgewerkt: Friday, March 13, 2026
