WOHNER 32431 EQUES EasyConnector

Wohner 125A Busbar Adapter EQUES EasyConnector 32431 Description The Wohner EQUES EasyConnector, part number 32431, is a high-quality 3-pole busbar adapter designed for the 60mm-System classic. It provides a safe and efficient method for connecting DIN rail mountable equipment, such as miniature circuit breakers, to a busbar power distribution system. With a rated current of 125A and a voltage rating of 690V, it is suitable for a wide range of industrial applications requiring robust power distribution. The adapter ensures a secure mechanical and electrical connection, simplifying panel assembly and maintenance. Order now from profideals for expert support and fast delivery. Specifications Manufacturer: Wohner Part Number: 32431 Rated Current: 125 A Rated Voltage: 690 V AC System: 60mm-System classic Poles: 3-pole Mounting: For DIN rail mountable devices Label Info Model: EQUES EasyConnector Art.Nr: 32431 Ue: 690V Ie: 125A Standard: IEC 60439-1 Made in: Germany Application Ideal for use in industrial control panels, switchboards, and power distribution units where DIN rail devices need to be integrated directly onto a 60mm busbar system. It is commonly used in machine building, process control, and building automation. Country of Origin Made in Germany. CO2 Impact By choosing this pre-owned component, you are helping to prevent the emission of approximately 16 kg of CO2. This saving is comparable to the CO2 absorbed by a mature tree in a year or driving a car for 80 kilometers. Availability This item is in stock and ready for immediate dispatch. FAQ What is the maximum width of the DIN rail device that can be mounted on this adapter?This adapter is designed to accommodate standard DIN rail devices. The total usable width is approximately 162mm, allowing for several smaller components or a larger moulded case circuit breaker adapter to be fitted. Is this adapter compatible with busbar systems other than Wohner’s 60mm-System classic?This adapter is specifically designed and tested for use with the Wohner 60mm-System classic and compatible systems with the same busbar center-to-center spacing. Using it with other systems is not recommended and may compromise safety and performance. What is the tightening torque for the terminal screws connecting to the busbar?The required tightening torque is critical for a secure connection and is specified in the installation instruction sheet (No. 94 255) from Wohner. Always refer to the manufacturer’s documentation to prevent over-tightening or loose connections. Last Update: Friday, March 13, 2026 profideals is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners.
